Patriot® Cone Crusher
GUARANTEED FOR REAL LIFE
Typically applied in secondary and tertiary stages, the cone crusher produces reduction ratios of 6:1 to 4:1.
Bushing cones, like Superior’s Patriot Cone Crusher, consist of a rotating mantle inside a steel bowl. As rock is compressed between the mantle and the bowl, the force generated fractures the material. This process continues until the pieces are small enough to fall through the bottom.
Superior manufactures several cone models:
- Maximum feed size up to 12 7/16″ (316mm)
- Final product size of 5″ – minus #6 (125mm – 3mm)
- Maximum tonnage rate of 820 STPH (745 MTPH)
resources
01.
Countershaft
If clamping pressure is lost, the counterclockwise rotation opens the crusher rather than turning down and causing significant damage.
02.
Crushing chamber
Universal design requires no major change-outs when shifting to and from secondary and tertiary applications.
03.
Tramp cylinders
Inverted cylinders means the hydraulic seals are not exposed to contamination during operation.
04.
Tramp relief
Designed with fewer accumulators for less maintenance and common points of failure.
05.
seating surface
Machined surface can be reconditioned up to 3X in the field without additional welding inside a shop.
06.
Pivot Point geometry
High pivot point design for a more active feed opening allows for more feed and fewer plugs.
P500 Patriot Cone Crusher VIDEOS
Unbelievable Warranty. Standard With Sale.
You’ll grow old with your cone crusher right by your side. Introducing the industry’s first lifetime cone protection.
Vantage® Automation
Option for patriot cone crushers
One button auto-start or auto-stop control
Startup and shutdown correctly every time
No lengthy training, learn in minutes
Automatically maintain optimum production
Alarms alert for harmful conditions
Patriot Cone Crushers in Application
Alberta Aggregates – Alberta, canada
Accustomed to our conveying equipment, Alberta Aggregates upgraded to a new Patriot Cone Crusher and is enjoying the benefits of more production.
Maverick Crushing – Tooele, Utah
Marty admits to a bit of skepticism when there’s a newcomer in a well-established industry. Watch to learn of this crushing veteran’s instant appreciation of the Patriot Cone.
Stock Inventory
Most of the time, we rely on our dealers to stock Superior equipment. However, we typically have a small amount of factory stock.
